The Amana DS01G Wireless Occupancy Sensing Wall Thermostat combines wire-free digital climate control with an integrated Passive Infrared (PIR) motion sensor. Engineered specifically for Amana J-Series and K-Series Packaged Terminal Air Conditioners, this battery-powered thermostat automatically detects guest presence in the room and adjusts temperature set-points to an energy-saving setback level when the room is unoccupied.
Communicating via secure two-way Radio Frequency (RF) directly to the PTAC mainboard, the DS01G requires no external antenna on J/K-Series models and no wall wiring—saving property owners up to 35% in heating and cooling energy costs without sacrificing guest comfort.
Note: Native RF communication requires no external antenna for Amana J-Series and K-Series PTACs. When pairing with legacy Amana G or E Series units, the DT01G DigiTenna receiver is required. When pairing with Distinctions by Amana models, the GT01H GenericTenna is required.
Share
Automated Occupancy-Based Energy Management for Hotels & Multi-Family Facilities
HVAC operation in unoccupied rooms represents one of the largest controllable utility wastes in hospitality and multi-family operations. Guests frequently leave air conditioning or heating running at extreme temperatures when leaving for the day. The Amana DS01G Wireless Occupancy Sensing Thermostat addresses this directly by combining precise digital wall control with automated Passive Infrared (PIR) motion sensing.
How Temperature Setback Technology Cuts Building Overhead
The DS01G continuously monitors room activity using a wide-angle PIR thermistor. When no motion is detected for a configurable duration, the thermostat automatically initiates an energy-saving setback mode—adjusting the target temperature by several degrees to reduce compressor and heater workload. As soon as a guest re-enters the room and triggers the motion sensor, the DS01G instantly restores the temperature to the guest's selected comfort setting.
Native Board Integration & Zero Wire Fishing
Amana J-Series and K-Series PTAC chassis feature a built-in RF receiver directly on the control board. Because the receiver is already integrated into the unit, the DS01G pairs wirelessly with zero external wiring, wall cutting, or conduit installation. Maintenance staff can complete an entire room upgrade in under two minutes by putting the PTAC into learn mode and pressing the single pairing button on the back of the thermostat.
Multi-Stage Control & Commercial Features
2-Stage Heat / 1-Stage Cool Control: Fully compatible with both conventional electric heat (PTC) and heat pump (PTH) PTAC units.
2-Speed Blower Selector: Front panel controls allow guests to select Fan LOW, Fan HIGH, or Fan AUTO operation.
Battery-Powered Flexibility: Powered by standard AA alkaline batteries, eliminating hardwired electrical connections and ensuring settings remain active during power interruptions.
Standalone or Eden EMS Network Ready: Can be deployed as a standalone room setback thermostat or integrated into a comprehensive Amana Eden wireless energy management network.
Integrated PIR Motion Sensor: Wide-angle passive infrared thermistor detects room movement for automated setback triggering.
Two-Way RF Communication: High-reliability radio frequency signals connect the wall unit directly to the PTAC mainboard.
Large Backlit Digital Screen: High-contrast digital readout illuminates upon button press for clear visibility.
2-Speed Blower Management: Controls Fan LOW, Fan HIGH, and Fan AUTO operations for customized room airflow.
Field-Adjustable Setback Parameters: Property managers can configure setback temperature offsets and setback delay times.
Low-Battery Display Indicator: On-screen icon alerts engineering staff when AA batteries require replacement during routine audits.
Model / SKU DS01GOfficial Amana OEM Wireless Occupancy Thermostat
Power Source 2x AA Heavy-Duty Alkaline Batteries (Included)Battery powered (No C-wire required)
Occupancy Sensor Type Passive Infrared (PIR) Motion ThermistorIntegrated front-bezel motion lens
Communication Protocol 2-Way Radio Frequency (RF) TransmissionsOperates through furniture without line of sight
J / K Series Antenna Req. NONE (Built-in board RF receiver)Direct native board pairing
G / E Series Antenna Req. DT01G DigiTenna Receiver RequiredOptional adapter for legacy retrofits
Distinctions Series Req. GT01H GenericTenna Receiver RequiredOptional adapter for Distinctions models
System Compatibility 2-Stage Heat / 1-Stage CoolSupports PTC (Electric Heat) & PTH (Heat Pump)
Fan Speed Control 2-Speed (Low / High / Auto)Front-panel push-button selector
Dimensions 4.53" W x 4.53" H x 1.2" D Standard square wall plate profile
Color Finish Commercial Off-White Neutral finish matching modern guest room decor
